Application
dyestuff, coating, ink, pigment
Basic technical parameter
| Type | 3.5L | 50L | 100L | 200L | 300L | 500L | 1000L | 1500L | 2000L | 3000L |
| Speed of grinding barrel(r/min) | 40 | 55 | 50 | 50 | 50 | 45 | 40 | 35 | 35 | 28 |
| Motor power(kw) | 0.15 | 2.2 | 3 | 4 | 5.5 | 75 | 15 | 15 | 18.5 | 22 |
| Volume of grinding barrel(L) | 3.5 | 50 | 100 | 200 | 300 | 500 | 1000 | 1500 | 2000 | 3000 |
| Volume of material(L) | 0.1-0.2 | 20 | 40 | 90 | 130 | 200 | 450 | 700 | 900 | 1500 |
| Volume of ball(L) | 0.25 | 25 | 50 | 100 | 150 | 225 | 500 | 750 | 100 | 900-1400 |
| Weight(KG) | 5 | 100 | 220 | 380 | 510 | 780 | 1060 | 1600 | 2200 | 5200 |
Feature
◆It is more effective to easy return thickening material.
◆Grinding and dispersing under confined condition to avoid volatilization of solvent
