Application
ISF versatile sand-milling dispersing-agitator (frequency control) concentrates sand-milling, dispersion and agitation versatile equipments functions, it is ideal for chemical industry slab oratory. It adopts motor of frequency control, heating is lower, there is no need for carbon brush, frequency converter adopts multiloop frequency-changer speed button, direct digital display axis revolution, it is easy to operate; it is equipped with sand-milling disc, dispersing blade and agitating blade. It can fit different testing need of laboratory
Basic technical parameter
| Type | ISF-400 | ISF-550 | ISF-75 | ISF1.1 | ISF-220 |
| Power kw | 04 | 055 | 0.75 | 11 | 2.2 |
| Container capadty L | 1-5 | 1-5 | 1-5 | 5-10 | 20-50 |
| Grinding media | Glass bead/ zirconia bead | ||||
| Elevating hight mm | 200 | 200 | 260 | 400-500 | 400-500 |
| Speed r/min | 0-8000 | 0-10000 | 0-2800 | 0-2800 | 0-2800 |
| Weight kg | 40 | 40 | 50 | 80 | 150 |
| Overall dimension mm | 450×450×900 | 450×450×900 | 450×450×930 | 520×500×1300 | 600×720×1600 |
